descriptions of the parameters .
parameter group number
Communication access address
F0~FC group
0x0000～0x0EFF
d0 group
0x7000～0x70FF
Communication settings:
The communication setting value is the percentage of the relative value,
10000 corresponds to 100.00%, -10000 corresponds to -100.00%;
parameter
address
Parameter Description
1000H
Communication setting value (decimal)
–10000 to 10000
Control command input to inverter: (write only)
Command word address
Command function
2000H
0001: Forward running
0002: Reverse operation
0003: Forward jog
0004: reverse jog
0005: Free stop
0006: Decelerate to stop
0007: Fault reset
Read drive status: (read only)
Status word address
Status word function
3000H
0001: Forward running
0002: Reverse operation
0003: Downtime
Inverter fault description:
Frequency
inverter
fault
address
Inverter fault information
8000H
0000: No fault
0002: Acceleration overcurrent
0003: Deceleration overcurrent
0004: Constant speed overcurrent
0005: Acceleration overvoltage
0006: Deceleration overvoltage
0007: Constant speed overvoltage
0008: Software deceleration overcurrent
0009: Undervoltage fault
000A: Inverter overload
000B: Motor overload
000E: Over temperature fault
000F: External input failure
0010: Communication failure
0012: Current paranoid error
0013: PID feedback overrun
0014: PID feedback value is low
0015: Parameter setting failure
001F: PID feedback lost during operation
0070: EEPROM fault
The rest not listed are reserved
