Zest ZQ280S2D2 - Function Parameter Specifications; F0 Group: Basic Running Parameters

Function
code
Name Description
Setting
range
Factory
default
F0.00 VF Power The current power of the VFD.
0.00-
99.99KW
Model setting
F0.01 Control Mode
0：V/F Control
1: SVC mode
0-1 0
F0.02 Running order channel selection
0：Keyboard command channel
1：Terminal command channel
0-1 0
F0.03
Frequency given source channel
A
0：Digita setting (UP/DOWN terminals
requlate,Off electricity does not storage)
1：Digita setting 2(UP/DOWN terminals
requlate,Off electricity storage)
2：AVI analog setting（0～10V）
3：ACI analog setting（0～20mA）
4：Keybord potentiometer setting
5：Multi-speed setting
6：Simple PLC
7：PID control
8：Communication(ZQ280A Only)
0-7 4
F0.04
Frequency given source channel
B
0：Digita setting (UP/DOWN terminals
requlate,Off electricity does not storage)
1：Digita setting 2(UP/DOWN terminals
requlate,Off electricity storage)
2：AVI analog setting（0～10V）
3：ACI analog setting（0～20mA）
4：Keybord potentiometer setting
5：Multi-speed setting
6：Simple PLC
7：PID control
0-7 0
F0.05
Channel A and Channel B
calculate result selection
0：Ａ+Ｂ
1：Ａ-Ｂ
2：MAX（Ａ，Ｂ）
3：MIN（Ａ，Ｂ）
0-3 0
F0.06
Frequency given source
selection
0: Main frequency A
1: Channel A and Channel B calculate
result(Refer to F0.05)
2: Switch Channel A to Channel B
3: Switch Channel A to Channel A and Channel
B calculate result
4: Switch Channel B to Channel A and Channel
B calculate result
0-4 0
F0.07 digital frequency setting
The set value is the initial value of frequency
digital given
0-MAX
Frequency
50.00Hz
F0.08 Max frequency output
The maximum output frequency is the highest
frequency that the VFD allows to output, and it is
the benchmark for acceleration and deceleration
settings.
Upper limit
frequency -
400.00Hz
50.00Hz
F0.09 Upper limit frequency
The operating frequency cannot exceed the
maximum output frequency of this frequency
Lower limit
frequency -
Max
frequency
50.00Hz
F0 group-Basic running Parameters
Function Parameter Specifications
8
