SECTION
INTRODUCTION
RESPONSIBILITIES
The customer/operator is responsible for carrying out the maintenance checks described in this hand-
book to ensure the efficient and safe operation of the marine gearbox.
Each marine gearbox is covered by warranty, which is only valid if the instructions in this manual are
strictly adhered to.
ATTENTION
ZF PADOVA S.p.A. is not liable for any damage or loss caused by the incorrect installation, improper
use or lack of maintenance of the equipment.
ZF PADOVA S.p.A is not responsible for any torsional vibration caused by the incorrect interaction
between engine, shaft and propeller. This torsional vibration may damage the engine and/or marine
gearbox.
MARINE GEARBOX IDENTIFICATION
The identification plate is affixed to the marine gearbox itself.
Read the instructions handbook before proceeding with the installation.
SERIAL No
RATIO
TYPE
OIL TYPE
OIL CHANGE: after first 50 hours of operation and every
1000 hours or 12 months, wichever occurs first.
CHECK OIL LEVEL WEEKLY
OIL
CAPACITY (dm
3
)
CLUTCH OIL
PRESSURE(bar)
CUSTOMER No
MASS DRY (Kg)
PART LIST No
ContinousMediumLightPleasure
Fig. 1 Fig. 2
Fig. 3 Fig. 4
ZF 350 A ZF 350 V
ZF W 350
ZF 350 IV
