ZF 350 Series User Manual

8
ZF PADOVA
The gearbox can be supplied with or without optionals (oil cooler, flexible coupling, brackets, trolling
valve).
Gearboxes are supplied without oil.
POS. DESCRIPTION
1
2
3
4
5
6
7
8
9
PTO cover
Oil pump
Output shaft
Suction filter
Drain plugs
Casing
Oil sump
Oil dipstick
Breather
POS. DESCRIPTION
10
11
12
13
14
15
16
17
18
Oil cooler
Filler plug
Shift control linkage bracket
Control valve
Valve control lever
1/8 NPTF pressure connector
M14x1.5 plug
Oil Filter
Check cover
Table 1
10
3
6
2
13-14
7
1
16
2
14
5
10
13
8
6
3
11
4
ZF W 350
ZF 350 IV
Fig. 7
Fig. 8
1
5
11
15
8
9
4
18
16
12
17
18
17
9
