7. TIGHTENING TORQUES
PART
SIZE
TORQUE
IN lb.ft.
TORQUE
IN Nm
LOCTITE
Mounting brackets bolts
ZF 63 A - ZF 63
M12 min 55.5 - max 57 min 75 - max 77 -
Mounting brackets bolts
ZF 80 A - ZF 80-1 A - ZF 85 A
M12 min 55.5 - max 57 min 75 - max 77 -
Output flange bolt
ZF 63 A - ZF 63
M16 74 100 243
Housing bolts
M10 30 40 -
Control block bolts
M8 13 18 243
Shifting lever bolt
M8 17 23 -
Output flange bolt
ZF 80 A - ZF 80-1 A - ZF 85 A
M16 74 100 243
Fluid filter bolt
M8 min 4 - max 6 min 5 - max 8 -
Oil breather
- Hand tight Hand tight 574
Fluid dipstick
- Hand tight Hand tight -
Oil drain plug
- 30 40 243
Stud bolt
M16 26 35 243
Control block stop screw
- 9 12 -
Control block pressure screw
M10 9 12 -
Screw ZF 63 A
M5 4 5 243
Screw ZF 80 A - ZF 80-1 A - ZF 85 A
M6 7 9 243
Neutral safety switch
- 18.5 25 -
Control block guide bolt
- 9 12 -
Control block temperature plug
-26 35-
29
Repair Manual and Spare Parts List Section 7
