8. FUNCTION TEST
30
Repair Manual and Spare Parts List Section 8
When the transmission has been completely assembled
and filled up with transmission fluid, it would be conve-
nient to make a function test.
This test can be carried out on a bench test rig, or in a
boat. If no fluid cooler can be connected, a hydraulic
hose must be connected between the inlet and outlet
of the hydraulic pump.
Measuring instruments required:
.
Pressure gauge 0-40 bar (0-580 psi), with connect-
ing thread M10x1.
.
Temperature gauge 0-120ëC (0-250ëF) connecting
thread 3/8«-18NPSF.
.
Flow meter 0-35 liters/min (0-10 gals/min).
Tests to be carried out:
1. Fluid leaks
2. Noise emission
3. Output direction of rotation, LH/RH
4. Lube oil temperature
5. Shifting pressure
6. Lube oil flow rate
The function test should be carried out follows:
Motor speed
rpm
Shift lever
position
Temperature
Durat.
minutes
Test
800-1000 neutral 40ëC/104 ëF 5 1, 2
600-800
(idling speed)
A<->B
position repeatedly
40ëC/104 ëF - 1, 2, 3
1500-2500 B position 80ëC / 176 ëF - 1, 2, 4
600-800
(idling speed)
A<->B
position repeatedly
80ëC/176 ëF - 1, 2, 3
idling - max. speed A position 80ëC/176 ëF - 1, 2, 5
]
,6
]
600-800
(idling speed)
A->B
position 80ëC/176 ëF
- - 1, 2
idling - max. speed B position 80ëC/176 ëF - 1, 2, 5
]
,6
]
80ëC/176 ëF -
]
At different speeds.
