REQUIRED PARTS AND TOOLS
Page 13
3.3 CONTROL SYSTEM POWER
The Processor requires:
A battery source of 12 or 24 volts DC
A 10 ampere circuit breaker with manual reset
Automatic Power Selector (refer to Appendix A.1 - S-214
APS Service Sheet)
The power for the Control System should come from the same power
distribution panel as the other required engine functions. (Refer to
Appendix C.1 Drawing Notes)
3.4
CLUTCH POWER SUPPLY
The power for the clutch solenoid may come from the same power
distribution panel as the other required engine functions. The Clutch
Power Supply cable and the Processor DC Power Source cable may
come from the same breaker. (Refer to Appendix C.1 Drawing Notes
for power requirements.)
3.5
CABLE HARNESS
Below is a general list of Wire Harnesses available to CruiseCom-
mand. Not all of the harnesses may be used on every system. The
use of the harness depends on the features being used on the vessel.
A complete harness list and part numbers are located in Appendix
A.1.
Station 2, Station 3, Station 4, Pulse, and Serial connectors on the
Processor are sealed with plugs at the factory. If the connectors are
to be used, remove and discard these plugs. Every connector should
either have a Wire Harness or plug. Do not leave a connector empty.
All Harnesses are available from ZF Mathers, LLC. Select from
Appendix A.1 – Parts List the correct Harnesses for your System.
