Quick start guide
How to Charge
FIVERAY F adopts high-capacity built-in lithium battery, providing
a solidly long runtime. The battery level is displayed on the screen. The
following methods show how to charge your FIVERAY F:
① Use Type-C cable to connect USB chargers to the Type-C port of
FIVERAY F100, and plug the USB charger into an AC socket. It is
recommended to use USB chargers that meet the PD protocol
(support 100W at most).
② Connect the TransMount 120W Power Adapter to the DC charging
port and the AC socket to charge FIVERAY F100.
How to Use ZHIYUN FIVERAY F
1.Buttons
Note: USB charger and USB cable that supports W fast charging
are not included in the package. FIVERAY F COMBO offers a
TransMount W Power Adapter.
TransMount W Power Adapter
USB Type-C cable
USB Charger
AC power
（-V）
AC power
（-V）
MAX
FX
①
②
③
④
⑤
⑥
①DIM Mode Button：
Single press:
Enter brightness adjustment interface
under CCT mode.
Switch between brightness/color
temperature (brightness adjustment interface).
②Dial：
Adjust parameters.
Switch light effect types (light effect interface).
③HSI Mode Button:
Single press: Enter HSI Full-color interface.
Switch among Hue (H)/Saturation (S)/Intensity (I) (HSI Full-color interface)
④Max Power Button：
Single press to enable/disable full power (CCT mode).
⑤Power/Parameter Switch：
Long press: Power on/off.
Double press:
Quick adjustment of brightness/color temperature (CCT mode).
Quick adjustment of Hue (H)/Saturation (S)/Intensity (I) (HSI mode).
Quick adjustment of brightness (FX Light Effect mode).
⑥FX Light Effect Mode Button：
Single press:
Enter the light effect adjustment interface under FX Light Effect mode.
Switch between brightness/light effect (light effect adjustment interface).
