3
11. WB Button*
Single press to enter white balance
settings, then rotate the quick
adjustment wheel to adjust white
balance parameters
12. 1/4 Screw Hole
For 1/4 screws.
13. Joystick
Rotate the joystick in four directions to
control the stabilizer. (Not available in
Go mode and POV mode)
14. Video Button
• Single press to start or stop the
camera filming.
15. Photo Taking Button
• Half-press to activate autofocus on
certain cameras (in Screen Record
Album, single
press to play or pause the video)
• Full-press to take photos
16. Quick Control Dial
• Single press TV/AV/EV/ISO/WB
button and rotate the quick control
dial to adjust the corresponding
parameter of the camera.
• Rotate the dial in Screen Record Alb
um to select video file
• Rotate the dial to adjust parameters i
n Settings Menu
17. F1 Motion Sensor Button
Single press to turn on or turn off
motion sensor.
18. F2 Screen Record Button
Single press to turn on or turn off
Screen Record.
19. External Battery Slot**
Install NP-F external battery.
20. Unlock Button
Press to take out the rear cover of the
external battery slot or the external
battery.
21. Quick Adjustment Wheel
• Single press TV/AV/EV/ISO/
WB button and rotate the quick
adjustment wheel to adjust the
current parameter of the camera.
22. Zoom Rocker
Control electronic zoom of some
cameras or TransMount Zoom/Focus
Control Motor.
23. Power Button
• Press and hold for 3 seconds to
power on or turn off
• When it’s turned off, press and hold
for 7 seconds to upgrade
• When it’s powered on, single press
to lock all control buttons and hide
the icons on the screen, press again
to unlock
24. Battery Indicator Light
Show the current battery level of the
Visual Controller.
Get to Know ZHIYUN MasterEye Visual Controller VC100
* The parameter cannot be adjusted when the camera is in certain modes. Please refer
to the current exposure mode of the camera.
** Install NP-F batteries (not provided) to the external battery slot to extend runtime.
