Zhiyun SMOOTH 4 User Manual

8
The Use of Stabilizer
⓬
Video Button [ ]
Single press to start or stop recording.
⓭
Mode Switch Button
●
Push slider up to enter PF(Pan Following) Mode;
●
Push slider down to enter L(Locking) Mode.
⓮
Power Button [ ]
Press the button for 2 seconds to turn on/off the
stabilizer;
⓯
Battery Level Indicator
●
The button shows how much power is left.
●
0~25%: one blue light;
●
25~50%: two blue lights;
●
50~75%: three blue lights;
●
75~100%: four blue lights.
⓰
“PhoneGo” Mode Button - Full-speed Following
Mode Button
When pressing this button, the stabilizer enters Full-
speed Following Mode - “PhoneGo”. Smooth 4 can
then follow your move synchronously at full speed.
⓱
Following Mode Button
●
When pressing the button, the stabilizer enters
following mode;
●
When double pressing the button, the tilt axis
motor and roll axis motor go back to initial state.
1. In standby mode, the stabilizer can still adjust
phone camera parameters;
2. Part of the function buttons mentioned
above can only be used when the stabilizer is
connected to "ZY Play" App in the phone.

Zhiyun SMOOTH 4 Specifications

General

Type	Smartphone camera stabilizer
Material	-
Product color	Black
Maximum weight capacity	0.21 kg
Mechanical roll range	0 - 240 °
Charging time	3.5 h
Operating time	12 h
Battery voltage	7.4 V
Battery capacity	2000 mAh
Built-in battery	Yes
Operating temperature (T-T)	-10 - 45 °C
Package depth	374 mm
Package width	157 mm
Package height	70 mm
Package weight	888 g
Cables included	USB

Weight and Dimensions

Depth	105 mm
Width	123 mm
Height	328 mm
Weight	547 g
