Zhiyun SMOOTH 4 User Manual

16
Firmware Upgrade Step
USB
Connect the stabilizer to your computer via Micro USB
cable to get ready for the firmware upgrade and calibration.
1. Visit ZHIYUN’s offcial website: www.zhiyun-tech.com;
Click “DOWNLOAD” and find the Firmware Upgrade
Tutorial package, then download the driver, calibration
tool and latest firmware corresponding to your stabilizer.
(USB driver installation is not needed for Mac and WIN
10 system).
2. Connect the stabilizer to your computer via Micro USB
cable, power on the stabilizer and finish the installation of
the driver.
3. Power on the stabilizer and long press mode button to
enter standby mode.
4. Enter the downloaded “Zhiyun Gimbal Tools” and
upgrade firmware following the instructions indicated in
the Firmware Upgrade Tutorial.
Calibration and Firmware Upgrade
Motor Fine-tuning
Please refer to “APP Operations” on Page 13
for more information; Connect the stabilizer to
ZHIYUN’s APP - ZY Play - via Bluetooth, enter “PTZ”
and adjust the value of the tilt and roll axis angle to
your actual needs.

Zhiyun SMOOTH 4 Specifications

General

Type	Smartphone camera stabilizer
Material	-
Product color	Black
Maximum weight capacity	0.21 kg
Mechanical roll range	0 - 240 °
Charging time	3.5 h
Operating time	12 h
Battery voltage	7.4 V
Battery capacity	2000 mAh
Built-in battery	Yes
Operating temperature (T-T)	-10 - 45 °C
Package depth	374 mm
Package width	157 mm
Package height	70 mm
Package weight	888 g
Cables included	USB

Weight and Dimensions

Depth	105 mm
Width	123 mm
Height	328 mm
Weight	547 g
