Zhiyun SMOOTH-Q2 User Manual

6
How to Use
Motors circled in red will auto move with the stabilizer, while motors circled in grey
are locked.
Single click or double click the joystick to switch between modes.
Locking Mode
L
Following
Mode
F
POV Mode
POV
Vortex Mode
V
Pan Following
Mode
PF
Double click
Single click
Double click
Single click
Pan Following Mode (PF):
Phone camera pans left/right following the movement of the stabilizer handle while the
tilt and roll axis motors are locked. Push the joystick up/down to control the tilt axis.
Stabilizer Mode Description
Default
Double click
Single click
Double click
Single click
Double click
Single click

Zhiyun SMOOTH-Q2 Specifications

General

Type	Smartphone camera stabilizer
Material	Aluminum
Motorized	Yes
Applicability	Universal
Product color	Black
Number of axis	3
Angle of rotation	360 °
Compatible products	Google: Pixel XL, Pixel 2 XL, Pixel 2, Pixel, Nexus 6P, Nexus 6, Nexus 5X Samsung: Galaxy S9 Plus, Galaxy S9, Galaxy S8 Plus, Galaxy S8, Galaxy Note 8 Huawei: P9, P20 Pro, P10 Plus, P10, Mate 9, Mate 8, Mate 10 Pro, Mate 10 Oneplus: 6, 5T, 5, 3T, 3 Xiaomi: Redmi Note 4X, Redmi Note 3, MI 6, MI 5s, MI 5, MI 4 LG: G6, G5 Oppo: R9s, Find X Vivo: X7, NEX
Maximum device width	86 mm
Minimum device width	65 mm
Maximum weight capacity	0.26 kg
Charging time	3 h
Operating time	17 h
Battery voltage	3.6 V
Battery capacity	4500 mAh
AC adapter output current	2 A
AC adapter output voltage	5 V
Operating temperature (T-T)	-10 - 45 °C
Mechanical roll range	0 - 265 °
Mechanical tilt range	0 - 305 °
Bluetooth version	5.0
Cables included	USB
Country of origin	China

Weight and Dimensions

Depth	266 mm
Width	121 mm
Height	54 mm
Weight	517 g
