14
ASSEMBLY OF YOUR
ZHUMELL ECLIPSE TELESCOPE
STEP 2: While supporting the OTA with your hand, close and tighten the OTA Rings over the entire
assembly. Double-check that these connections are secure before moving on - damage to the OTA is likely
to be irreparable.
ATTACHING THE FINDERSCOPE
8
STEP 1: Locate the two screws on top of the OTA and remove the heads. Attach the Finderscope Bracket
using the two exposed screws and fasten securely with the heads.
STEP 2: Slide the Finderscope into the Finderscope Bracket with the smaller end pointing downwards.
Fasten into place using the three thumbscrews on the Finderscope Bracket. Fine-tuning adjustments can be
made later.
