Technical data
System
Nominal supply voltage /
frequency
220V
AC
, 60Hz 120 V
AC
, 60 Hz
Power supply fuse rating L 20 A at 120V
AC
L16 A at 220V
AC
Required residual current
circuit breaker (RCD)
I
N
≥ 20 A, I
AN
= 30 mA at 120 V
AC
, 60Hz
I
N
≥ 16 A, I
AN
= 30 mA at 220 V
AC
, 60Hz
Nominal supply current 10 A continuous, 22 A short-time at 120V
AC
16 A short-time at 120V
AC
Power supply in standby
mode
3.75 A / 450 W at 120 V
AC
(applies to the following configuration: Standard
monitors, printer UP980, CD writer, MO disk drive,
floppy disk drive)
The values depend on the integrated documentation
systems.
Internal fusing 20 A quick-blow (2
pcs.)
Maximum line impedance ≤ 0.6 Ω
Equipment protection
classification
Protection Class I, Type B ( ), ordinary equipment,
continuous operation
Radiation controlled area
(with generator in
lowermost position and
C-arm vertical)
23/31 cm i.i.: 4 m
