Maintenance Report: Technical data
Generator
Power Direct radiography:
Fluoroscopy:
- Pulsed mode:
40–110 kV
15 mA min./20 mA max.,
1.5 mAs min./100 mAs max.
40–110 kV
0.1–15 mA at 120 V
AC
0.2 mA at 230 V
AC
Pulse width 10, 16, 20, 30 ms
1, 2, 5, 10, 15, 30 pulses/s
Digital radiography
(snapshot):
Operating
frequency:
40–110 kV
0.1 mA min./18 mA max.
40 kHz
Max. operating data Fluoroscopy
Direct radiography:
Digital
radiography:
110 kV / 15 mA
110 kV / 18 mA
80 kV / 20 mA
110 kV / 16 mA
80 kV / 18 mA
Max. power output Fluoroscopy:
Direct radiography:
1650 W (110 kV / 15 mA)
1980 W (110 kV / 18 mA)
Digital
radiography:
1760 W (110 kV / 16 mA)
Nominal electric power 2000 W at 100 kV / 20 mA / 0.1 s
X-ray tube Single-focus stationary-anode tube
Focal spot nominal size 0.6 acc. to IEC
Total filtration ≥ 3 mm Al, including 0.05 mm Cu
Image intensifier
Tube Input screen:
Nominal sizes:
Caesium iodide
31 / 23 / (17) cm or
23 / 17 / (10) cm
Anti-scatter grid Pb 8/40
