Maintenance Report: Technical data
Table 2 Technical data of the Ziehm Vision (USA)
Monitors
Standard monitors Screen size:
Bandwidth:
Resolution:
440 mm (17")
140 MHz
1125 lines / 90 Hz
Flat screens 18.1" Screen size:
Resolution:
460 mm (18.1")
1280 × 1024
Flat screens 20.8" Screen size:
Resolution:
530 mm (20.8")
2048 × 1536
Environmental
conditions
During storage Temperature:
Relative air
humidity:
–10°C to +60°C
95% max.
During operation Temperature:
Relative air
humidity:
+10°C to +35°C
75% max.
Dimensions
C-arm Source–image
receptor distance:
970 mm
Vertical free space: 750 mm
Immersion depth:
Orbital rotation:
Angulation:
Swivelling (‘wig-
wag’):
Horizontal
movement:
Vertical movement:
680 mm
115° / 135°
a
± 225°
±10°
220 mm
430 mm
Weight
C-arm stand Ziehm Vision: approx. 280 kg (23 cm i.i.)
Monitor cart Ziehm Vision: approx. 203 kg
Ziehm Vision with
flat screens 18.1":
approx. 183 kg
Ziehm Vision with
flat screens 20.8":
approx. 188 kg
a. Option, not available with 31 cm i.i.
