ATTENTION: Decoders installed by the loco
manufacturer (OEM versions) may have fewer function
otuputs than shown here (i.e. only headlights, FO1, FO2),
as the model requires.
MX 645P 22 Top S id e (w ith P luX 22)
The SUSI outputs can alternatively
be used as servo outputs:
Function output FO3 Switch input
SUSI Data (Servo 2) SUSI Clock (Servo 1)
Capacitor positive Ground
Motor right Front headlight
Motor left Common positive (+)
Right rail ---
Left rail Rear headlight
Function output FO1 Speaker
Function output FO2 Speaker
Function output FO5 FO4
Function output FO7 FO6
(Index)
>220 uF
20 V
+ -
Cap.
pos.
Cap.
negative
(same as
Ground)
MX 645P 16 Top S id e (w ith P luX 16)
Program ming pads,
do not touch !
The SUSI outputs can alternatively
be used as servo outputs:
SUSI Data (Servo 2) SUSI Clock (Servo 1)
Cap. pos. Ground
Motor right Front headlight
Motor left Common positive (+)
Right rail ---
Left rail Rear headlight
Function output FO1 Speaker
Function output FO2 Speaker
(Index)
Capacitor as power back-up.
(is normally mounted on loco circuit board and connected via plug)
Function output FO8
Program ming pads,
do not touch !
Function output FO8
the same for MX645P22 and MX645P16.
+ -
MX 645 w ires o nly To p S id e
Program ming pads,
do not touch !
The SUSI outputs can alternatively
be used as servo outputs:
Function output FO1
Function output FO 2
Left rail
Rear headlight
Right rail
Motor right
Motor left
Front headlight
Common power (+)
Speaker
Speaker
purple
purple
White
blue
orange
gray
red
black
yellow
green
brown
SUSI Data (Servo 2) SUSI Clock (Servo 1)
Cap. pos.
Ground
Switch input
Function output FO3
Function output FO
Function output FO
Function output FO
Function output FO
4
5
6
7
MX 645 B otto m S id e (all Ty pe s )
+ 5 V (200 mA) for Servos etc. -- connect to tantalum
>220 uF
20 V
+ -
