ZIMO MX649N - Page 77

Non-Sound Decoder MX600 - MX638 and Sound Decoder MX640 - MX659 Page 77
Chap-
ter
CV
Denomination
Range
Default
Description
#469
#475
#481
#487
#493
#499
#505
Configuration 6 (1100xxxx) Output is turned off.
Config. 7 (1110xxxx) Output is turned on.
3.17
#434
#440
#446
#452
#458
#464
#470
#476
#482
#488
#494
#500
#506
A1 Reverse
0 – 255
0
Value range: 0, 1-13, 14-15
1. Output to be switched on in reverse direction.
0=no output, 1-13=FO1-FO13, 14=FO0v, 15=FO0r.
Bit 7-5: Refers to 5 PWM-Config-CVs(508-512).
Configuration 6 (1100xxxx) Output is turned off.
Config. 7 (1110xxxx) Output is turned on.
3.17
#435
#441
#447
#453
#459
#465
#471
#477
#483
#489
#495
#501
#507
A2 Reverse
0 – 255
0
Value range: 0, 1-13, 14-15
2. Output to be switched on in reverse direction.
0=no output, 1-13=FO1-FO13, 14=FO0v, 15=FO0r.
Bit 7-5: Refers to 5 PWM-Config-CVs(508-512).
Configuration 6 (1100xxxx) Output is turned off.
Config. 7 (1110xxxx) Output is turned on.
3.17
#508
Swiss-Mapping
PWM Value 1
0, 8 – 248
0
PWM-Value in Bit 7-3 - 0=Off, 248=100%
3.17
#509
Swiss-Mapping
PWM Value 2
0, 8 – 248
0
PWM-Value in Bit 7-3 - 0=Off, 248=100%
3.17
#510
Swiss-Mapping
PWM Value 3
0, 8 – 248
0
PWM-Value in Bit 7-3 - 0=Off, 248=100%
3.17
#511
Swiss-Mapping
PWM Value 4
0, 8 – 248
0
PWM-Value in Bit 7-3 - 0=Off, 248=100%
3.17
#512
Swiss-Mapping
PWM Value 5
0, 8 – 248
0
PWM-Value in Bit 7-3 - 0=Off, 248=100%
