ZINCKER VAULTA K1 - Install the latch and strike plate; Latch installation and centering

Hold the latch in front of the door
hole, with the latch face flush against
the door edge. Make sure the
square-shaped hole is centered.
For 2-3/4“ (70mm) backset, pull to
extend the latch in order to center
the squared-shaped hole.
Install the latch and strike plate
2
10
60mm70mm
