10Rear Hub Bearing Removal
Insert the 17 mm Bearing Puller slotted attachment through the drive
side bearing. Align the slotted attachment with the bottom of the
bearing, and expand it inside the bearing.
Do not over tighten the slotted attachment. For more detailed assembly
and usage, see the bearing puller manufacturer's instructions.
Grip the slide hammer and forcefully pull away from the slotted
attachment to remove the bearing from the driver body.
Insert the 17 mm Bearing Puller slotted attachment through the non-
drive side bearing. Align the slotted attachment with the bottom of the
bearing, and expand it inside the bearing.
Do not over tighten the slotted attachment. For more detailed assembly
and usage, see the bearing puller manufacturer's instructions.
Grip the slide hammer and forcefully pull away from the slotted
attachment to remove the bearing from the driver body.
8
17 mm Slotted Attachment
9
17 mm Slotted Attachment
