39Front Hub Bearing Installation
Install the wave spring onto the non-drive side of the axle. You may
need a tool to press the wave spring against the bearing face.
NOTICE
Do not scratch the axle when using a tool to install the wave spring.
The wave spring is crucial to hub performance and must be installed
onto the axle.
Apply grease to the following locations on the drive side and non-drive
side axle end:
• Axle front surface (a)
• Axle radial surface (b)
• Bearing front face across bearing seal, inner- and outer ring (c)
Press the end caps onto the axle.
Clean the hub with isopropyl alcohol and a shop towel.
7
8
Klüber Staburags NBU30 grease
a
c
b
9
10
Isopropyl alcohol Shop towel
