26Driver Cleaning (optional) - Coil Spring Driver
Using a grease syringe, apply a small amount of SRAM Butter grease to
the pawl slots.
Insert a coil spring into one of the lower spring slots, then install a
black pawl into the pawl slot.
Note: The springs and pawls are symmetrical and can be installed in
any orientation.
Use a small flat blade screwdriver to compress the spring to allow
the pawl to drop into the slot, then adjust the spring so that it is
perpendicular to the back of the pawl.
Insert a coil spring into the upper spring slot above the previously
installed pawl/spring, then install a silver pawl into the pawl slot.
Note: The springs and pawls are symmetrical and can be installed in
any orientation.
5
SRAM Butter Grease
6
7
Flat blade screwdriver
8
