Zipro Nitro - Parts List

22
EN
PARTS LIST
No. Description Quantity No. Description Quantity
1 Main frame 1 25 Flat washer D10 1
2 Bolt M5x10 2 26 Base cap, rear 2
3 Computer cable 1 27 Rear base 1
4 Heart rate measurement cable 2 28 Bolt M8x74 4
5 Saddle 1 29 Saddle column 1
6 Saddle horizontal position guide 1 30 Saddle height knob 1
7 Steering wheel 1 31 Saddle horizontal position knob 1
8 Flat washer 1 32 Handlebar cap 2
9 Separator 1 33 Handlebar foam 2
10 Handlebar column cover 1 34 Hexagonal nut M5x55 1
11
Handlebar angle adjustment
handle
1 35 Curved washer D5 1
12 Handlebar column 2 36 Resistance adjustment knob 1
13 Curved washer 8.5x1.5x25xr30 8 37 Resistance adjustment cable 1
14 Bolt M8x15 4 38
U-bracket for horizontal saddle
positioning
2
15 Handlebar column cover 1 39 Saddle guide cap, front and rear 2
16 Connecting cable 1 40 Saddle guide cap, upper 1
17 Computer 1 41 Saddle clamp 1
18L/R Base cap, front, left/right 1/1 42 Flat washer 3
19 Nut M8 4 43 Locknut 3
20 Front base 1 44 Water bottle 1
21L/R Left/right crank 1/1 45 Screw 2
22L/R Left/right pedal 1/1 46 Flat washer 2
23 Handlebar column cover 1 47 Water bottle holder 1
24 Bolt ST4.2x18 4 48
Towel holder
1
