Zipro Pacemaker - Parts List

28
EN
PARTS LIST
No. Description Quantity No. Description Quantity
1 Main frame 1 45 Bolt M8*45 S6 1
2 Inclination frame 1 46 Bolt M8*60 S6 2
3 Lower frame 1 47 Bolt M8*80 50 S6 1
4 Left treadmill column 1 48 Bolt M10*42 20 S17 1
5 Right treadmill column 1 49 Bolt M10*90 20 S17 1
6 Computer frame 1 50 Bolt M10*40 15 S6 4
7 Front roller 1 51 Bolt M8*60 20 S6 8
8 Rear roller 1 52 Bolt M8*20 S6 4
9 Cylinder 1 53 Bolt M6*40 S4 4
10 Flat washer
∮
60*
∮
36*3.0 2 54 Bolt M6*25 S4 4
11 Spring
∮
45X
∮
5 2 55 Bolt M8*35 S6 2
12 Running board t18*675*1275 1 56 Bolt M8*38 20 S6 2
13 Running belt t1.6*520*2890 1 57 Bolt M8*20 8*8*3 4
14 IGBT 1 58 Nut M8 S13 10
15 Motor cover 1 59 Nut M10 S17 6
16 Rear frame end cap 1 60 Washer
∮
8.5*
∮
19*t1.5 2
17 Lateral rail 2 61 Washer
∮
11*
∮
20*t1.5 6
18 L&R lateral rail cover 2 62 Washer
∮
8.5*
∮
12*t2.5 6
19 Front frame cover 1 63 Screw ST4.2*16 8
20 Lower cover 1 64 Screw ST4.2*16 26
21 L&R support cover 2 65 Screw ST4.2*12 30
22 Rear frame cover 1 66 Screw ST4.2*16 32
23 Rear foot cap 2 67 Screw ST3.9*16
∮
6 4
24 Handling wheel 2 68 Screw ST4.2*12 11
25 Damper 1 4 69 Screw ST4.2*16 4
26 Damper 2 4 70 Screw M5*10 2
27 Washer
∮
25*
∮
12*5.3 8 71 Screw ST4.0*15 2
28 Side left frame end cap 1 72 Sticky battens 4
29 Side right frame end cap 1 73 Washer
∮
5.2*
∮
10*t1 1
30 Cap 19*1.5 2 74 Signal cable 1
31 Cap 32*1.5 2 75 Earth system 1
32 Base cap 6 76 Single-conductor cable 18/270
mm
3
33 Hole plug 2 77 Computer cable 1
34 L&R foam handle cover 2 78 Power cord 1
35 Upper computer frame 1 79 Fuse 1
36 Lower computer frame 1 80 Switch 1
37 Display 1 81 Power cord clamp 6W3-4 1
38 Heart rate sensor 2 82 Screw driver S15*S13*S14*
∮
5*70 1
39 Speaker 2 83 Allen wrench S6 80*80 mm 1
40 Motor 1 84 Safety key 1
41 Inclination motor 1 85 Screw ST4.2*20 3
42 Belt angle adjustment mechanism 1 86 Motor frame 1
43 Display sticker 1 87 Mobile device holder 1
44 Button sticker 1 88 Bolt M8*12 S6 2
