PARTS LIST
No. Description Quantity No. Description Quantity
1 Main frame 1 36 Heart rate sensor / Quick
Start/Stop button
1
2 Lower frame 1 37 Safety key 1
3 Treadmill column 2 38 Signal cable 1
4 Upper frame 1 39 Hexagonal screw M8*45 1
5 Motor frame 1 40 Hexagonal screw M8*60 2
6 Front roller 1 41 Hexagonal screw M8*12 2
7 Rear roller 2 42 Hexagonal screw M8*20 2
8 Cylinder 1 43 Hexagonal screw M8*25 2
9 Running board t15*520*1130 1 44 Hexagonal screw M8*40 1
10
Running belt t1.4*400*2520
1 45 Hexagonal screw Φ10*15*(M8*10) 2
11 IGBT 200-J5 1 46 Hexagonal screw M8*15 2
12 Nut M6 8 47 Hexagonal screw M8*30 1
13 Motor 1 48 Hexagonal screw M8*25 2
14 Controller 1 49 Hexagonal bolt M8*45 9
15 Computer 1 50 Hexagonal screw M8*40 2
16 Upper motor cover 1 51 Bolt ST4. 2*12 2
17 Lower motor cover 1 52 Bolt ST4. 2*45 2
18 Left main frame end cap 1 53 Bolt ST4. 2*20 8
19 Right main frame end cap 1 54 Bolt ST4. 2*15 22
20 Main frame edge 2 55 Bolt M5*10 4
21 Lower frame handling wheel 2 56 Nut M8 8
22 Railing end cap 2 57 Washer Φ9* Φ16*t1.0 13
23 Foam grips 2 58 Spring washer D8 6
24 Plastic feet 4 59 Nut Φ 5.2* Φ 10*t1 1
25 Damper 8 60 Sensor 400 1
26 Electrical connector 1 61 Magnetic ring 1
27 Fuse 1 62 Single-conductor cable 1
28 Power cord 1 63 Two-conductor cable 2
29 Power cord clamp 6W3-4 1 64 Upper connecting cable 400 mm 1
30 Inclination adjustment 2 65 Heart rate sensor cable (1) 400
mm
1
31 Inclination adjustment lock 2 66 Heart rate sensor cable (2) 400
mm
1
32 Rubber damper washers 2 67 Wrench S17 / S13 1
33 Damper 2 68 Wrench S6 / 80*80 mm 1
34 Sticky battens 4 69 Bolt M6*40 8
35 Heart rate sensor / Quick speed
change +/-
1
