Battery charger NG3
D01058-02 7
Mechanical dimensions
90
220
370
430
78
6
N.B. All dimensions are expressed in mm.
Drilling details
UP
Advised Installation
N.B. All dimensions are expressed in mm.
=
=
60
60
18
13
6
220
399 430
100
