Battery charger NG5-7-9
D01274-00 7
Mechanical dimension
105130
270
470
550
N.B. All dimensions are expressed in mm.
Drilling details
UP
Advised Installation
N.B. All dimensions are expressed in mm.
16
9
16
70
70
518 550
130
260
