CMP-100A User Manual 3
2 Product Specifications and Structural Parameters
2.1 Specifications
Gate Bar
Length
Limit
(m)
Bar Rise
Duration
(s)
Bar Fall
Duration
(s)
Duration of a
Rise and Fall
Cycle
(s)
Height
Between the
Bar Center and
the Ground
(mm)
Body
Weight
(kg)
Body Dimensions
(mm)
6 6 6 12 830 45 350 x 280 x 1020
4.5 3 3 6 830 45 350 x 280 x 1020
3 3 3 6 830 45 350 x 280 x 1020
2.2 Technical Specifications
Input voltage
AC 220/110 V, 50/60 Hz
Rated power
90 W
Operating temperature of the motor (°C)
-30°C < C < 80°C
Chassis weight
55
Protection grade
IP44
Height Between the Bar Center and the Ground
830
Remote control distance
Not shorter than 30 m
2.3 Working Principle
The mechanical power produced by the motor drives the output shaft through the turbine and worm reducer and
transfers motion to the handle of the bar through a plane four-bar mechanism. Through a magnet induction switch,
the locations of the gate bar in the horizontal and vertical states during operation are accurately determined to
realize control over the gate bar.
