ZKTeco PL10 Installation Guide

58mm
(2-9/32")
(35/64")
(1-3/8")
(5/64")
(15/32"
35mm
14mm
(1-9/64")
29mm
21mm
(53/64")
12mm
2mm
6.Install the battery.
K
E
G
F
7.Mark and drill holes for strike.
8.Testing the lock by rotating back handle and using mechanical
key(A).
Note : When the door is l ocked, the clutch is in idle position, the front
handle will be turned. However, the door will remain locked.
9

ZKTeco PL10 Specifications

General

Brand	ZKTeco
Model	PL10
Category	Locks
Language	English
