Zline DW-WM-18 Manual

12
Wash Cycles
OPERATION
H - Hi Temp
When the Hi Temp wash function is selected, the temperature of the water
will be maintained at 140°F max.
NOTE: The Hi Temp option is available with Heavy, Normal, ECO, and Glass
cycles.
E - Energy Save
When the Energy Save function is selected, energy consumption will be reduced
during the washing process.
Note: The Energy Save option is available with Heavy and Normal cycles.
STATUS WINDOW
H:01- H:24
If the delay start option is selected, the number of delay start hours shows in the status
window.
2:25 - 0:00
After the machine starts operation, the remaining time of the selected cycle will be shown
in the window.
ERROR INDICATION
• In certain situations that are critical to dishwasher function and safe operation, the
appliance will shut down and indicate an error code (see Troubleshooting, page
20).
• If error codes are displayed and troubleshooting measures are unsuccessful, contact
ZLINE Customer Service at 1-614-777-5004 for help. We will be able to provide
assistance in troubleshooting the problem and/or locate an authorized service
technician if needed.
NOTE: The remaining time could suddenly increase or drop several minutes.
This means the smart sensor has checked the soil level and determined if
additional water fills are needed or if water fills can be deleted.

Zline DW-WM-18 Specifications

General

Style	built-in dishwashers
Color	white matte, matte white
Load Capacity	16
Number of Cycles	6
Options/Settings	energy save, quick wash, normal, rinse, eco wash, heavy wash, sanitary, high temperature wash, glass, heat dry option
Drying Type	heated drying
Noise level	40 decibels adjusted
Control Type	touchpad
Delay Start	yes
Number of Racks	2
Sanitize Settings	no
Annual Energy Consumption	234 kilowatt hours
Voltage	120 volts

Weight and Dimensions

Depth	23 inches
Height	32 1/2 inches
Width	17 3/4 inches
Net Weight	73.7 pounds
