STEP 6: INSTALL THE 90° WATER SUPPLY ELBOW
1. Wrap the male thread of the 90° elbow with Teflon thread seal tape twice.
Do not use plumber’s putty.
2. Install the 90° elbow onto the water valve. Do not overtighten the 90° elbow.
The water valve bracket could bend or the water valve fitting could break.
3. Position the end of the elbow to face the floor when the dishwasher is upright.
UP
DOWN
15
Step 6: Install the 90° water supply elbow
1 Wrap the male thread of the 90° elbow with Teflon thread seal tape twice. Do not use plumber's putty.
2 Install the 90° elbow onto the water valve. Do not overtighten the 90° elbow. The water valve bracket could bend or the
water valve fitting could break.
3 Position the end of the elbow to face the floor when the dishwasher is upright.
You’ll need:
Adjustable wrench
90° elbow
Teflon thread
seal tape
YOU’LL NEED
• Adjustable wrench
• 90
°
elbow
• Teflon thread seal tape
INSTALLATION
20
Water Supply
