If you have an installation problem, contact your dealer or installer. You are
responsible for providing adequate electrical, plumbing, and other connecting
facilities.
PREPARING TO INSTALL YOUR DISHWASHER
PARTS SUPPLIED
• Screws A - #8, 3/4”, Flat Head sheet
Metal Screw (4)
• Screws B - #8, 1/2”, Flat Head Sheet
Metal Screw (8)
• Screws C - #6, 7/8”, Flat Head Sheet
Metal Screw (2)
• Screws D - #6, 1 3/4”, Flat Head
Sheet Metal Screw (4)
• Top mounting clips (2)
• Hose clamp
• Drain hose
• Brackets (2)
• Top Hook Mounting Seats (2)
TOOLS NEEDED
• Phillips screwdriver
• 1/4” and 5/16” nut driver
• Level
• Flashlight
• Gloves
• Bucket
• Adjustable wrench
• Carpenters square
• Measuring tape
• Safety glasses
MATERIALS NEEDED (KIT PURCHASE SEPARATELY)
• 90° Elbow, ferrule and compression nut. (3/8” NPT external thread on one end. Other
end sized to fit water supply line
• Teflon thread seal tape
• Three wire nuts (UL listed) (two included in kit)
Not included in kit
• Hand shut-off valve
• Waste tee for house plumbing (if applicable)
• Screw-type hose clamps
• Coupler for extending drain line (if applicable)
• Air gap (if required)
PACKAGE CONTENTS
• Dishwasher
• Hose
• Installation Kits
• User Guide
• Installation Guide
BEFORE INSTALLATION
3
