Zline RC-PBT-30 User Manual

10
Wiring Schematics
120/208 V Ac 60Hz
120/240 V Ac 60Hz
WIRE CONNECTOR
GREEN
BROWN
WHITE
RED
白色
case fan
(RIGHT)
LAMP
(LIFT)
LAMP
SWITCH
FOR LAMP
Heat pipes-up
(INSIDE1800/2395 W,
OUTSIDE 650/865 W)
Heat pipes-down
2000/2670W
(LIFT)
oven fan
(RIGHT)
oven fan
GROUND
WIRE
SWITCH FOR
THERMOSTAT
SNAP
THERMOSTAT
SWITCH
MICROSWITCH 4
MICROSWITCH 3
MICROSWITCH 2
MICROSWITCH 1
IGNITION
ALLUMAGE
SWITCH FOR
ELECTRIC OVEN
RA30(RAB30-RAS30)电路图
120/208 V Ac 60Hz
120/240 V Ac 60Hz
WIRE CONNECTOR
GREEN
BROWN
WHITE
RED
Heat pipes-up
(INSIDE1800/2395 W,
OUTSIDE 650/865 W)
Heat pipes-down
2000/2670W
case fan
(RIGHT)
LAMP
(LIFT)
LAMP
SWITCH
FOR LAMP
(LIFT)
oven fan
(RIGHT)
oven fan
SWITCH FOR
THERMOSTAT
SNAP
THERMOSTAT
SWITCH
INDICATOR
LIGHT
IGNITION
ALLUMAGE
MICROSWITCH 1
MICROSWITCH 2
MICROSWITCH 3
MICROSWITCH 4
MICROSWITCH 5
MICROSWITCH 6
SWITCH FOR
ELECTRIC OVEN
GROUND
WIRE
RA36(RAB36-RAS36)电路图
Model: RC/RC-PBT-30
Model: RC/RC-PBT/RT/RTB/RTS-36
