ZOJE B9500 - Page 43

序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10008961 橡胶塞 rubber plug 1
2 10009198 送料轴 feeding shaft 1
3 10009239
挡圈
retaining spring 1
4 10002593 差动调节右曲柄
right crank of differential regulato
r
1
5 10009164 螺钉 screw 2
6 10002591 曲柄滑槽盖 crank slide trollgh cover 1
7 10002592 曲柄滑槽 crank slide trollgh 1
8 10009139 差动牙架滑块 sliding block 1
9 10008989 挡圈 rataining spring 1
10 10009625 螺钉 screw 2
11 10012162 内齿锁紧块 sliding block with inner teeth 1
12 10009298 销 Pin 2
13 10002890 螺钉 screw 1
14 10002887 扭簧 spring 1
15 10002885 针距调节凸轮 adjusting cam for stitch length 1
16 10003219 销 pin 1
17 10003218 送布偏心轮导轮
guiding wheel of feeding eccevtric wheel
1
18 10009327 送布偏心轮 feeding eccentric wheel 1
19 10002888 轴承 bearing 1
20 10002946 滚针轴承连杆 connecting bar 1
21 10002977 针距调节偏心轮片
eccentric wheel of stitch length regulator
1
22 10012162 螺钉 screw 2
23 10053036 针距按钮轴密封圈 oil seal 1
24 10009246 垫圈 washer 1
25 10009248 针距按钮轴弹簧 spring 1
26 10009249 针距调节按钮轴 button shaft 1
27 10003248 挡圈 retaining spring 1
28 10009040
针距按钮挡板 plate
1
29 10010595
螺钉 screw
2
30 10009000
差动调节连杆
differential regulating connecting ro
d
1
31 10009624
螺钉 screw
1
32 10009256 差动调节左曲柄
left crank of differential regulator
1
33 10009608 O型圈 O ring 1
34 10034607
差动调节轴 shaft of differential regultor
1
35 10009224
调节杆 adjusting bar
1
36 10009563
扭簧 spring
1
37 10009558
螺钉 screw
1
38 10009218
微调螺柱
screw
1
39 10003248
挡圈
retaining spring
1
40
10009205 弹簧 spring
1
41
10009203 螺母
nut
1
42
10009223 调节指示板 indication plate of adjustment
1
43
10009037 螺钉 screw
2
44
10009565 螺母
nut
1
45
10009564 垫片 washer
1
46
10009562 螺钉 screw
1
47
10009200 垫圈 washer
2
48
10009221 限位块 position plate
2
49
10003083
垫片
washer
2
50
10010554
螺钉
screw
2
13.差动送布机构(1)/DIFFERENTIAL FEED ASSEMBLY(1)
