ZOJE B9500 - Page 45

序号
No.
件号
Parts No.
名称 Description
数量
QT.
1 10009194 方口曲柄 crank with rectangular shaft 1
2 10009467 螺母 nut 1
3 10009192
垫圈
washer 1
4 10009193 送料连杆销
pin with thread for feeding connecting rod
1
5 10009164 螺钉 screw 1
6 10009137 抬牙调节偏心轴 eccebtric shaft 1
7 10009135 O型圈 O ring 1
8 10009136 挡圈 spring 1
9 10009117 偏心轴锁紧螺钉 screw 1
10 10009114 偏心轴锁紧螺钉橡胶垫 rubber cushion 1
11 10009166 挡圈 washer 1
12 10009074 螺钉 screw 1
13 10009140 差动牙架 stand of differential feed dog 1
14 10009134 抬牙调节滑块 sliding block 1
15 10009141 送料牙架 stand of feed dog 1
16 10066197 送料连杆 feeding connecting rod 1
17 10023487 连杆销套 bush connecting rod 1
18 10009192 垫圈 washer 1
19 10009142 螺钉 screw 1
20 * 主送料牙组件 body of main feed dog 1
21 10009586 螺钉 screw 2
22 * 差动送料牙 differential feed dog 1
23 10009133 抬牙滑块
sliding block for feed dog lifting
1
24 10036169 牙架导板组件 guiding plate of feed dog stand 1
25 10009102 螺钉 screw 4
26 10009161 外油封架 outer oil seal stand 1
27 10002975 螺钉 screw 4
28 10009081
牙架油封 oil seal
2
29 10037823
牙架油封 oil seal
2
*:参看专用件表/see the guage list
14.差动送布机构(2)/DIFFERENTIAL FEED ASSEMBLY(2)
