TECHNICAL SPECIFICATIONS
Product Name 11b+g WLAN USB Adapter
Standard IEEE802.11b/g
Frequency Band 2.400GHz ~ 2.4835GHz unlicensed ISM band
802.11b : QPSK/BPSK/CCK
802.11g : OFDM
Data Rate 54/48/36/24/18/12/11/9/6/5.5/2/1Mbps
Ad hoc
Infrastructure (Access Points is needed)
Transmitter Output Power < 15 dBm
Operating at 11Mbps: @ –80dBm
Operating at 54Mbps: @ –70dBm
Operating Range 30 to 200 m, depending on surrounding environment
Antenna Chip antenna
Security
64-bit, 128-bit or 256-bit WEP (Wired Equivalent Privacy);
WPA (Wi-Fi Protected Access)
I/O Interface USB 2.0/1.1
LED Link/Active
Operating system supported Windows 98Se, Me, 2000 and XP
Management Windows-based configuration utility and status monitoring
Regulation FCC for North America
CE/ETSI for European
Dimension 58(L) x 23(W) x 9(H) mm
Weight 9.6 g
Operating Temperature 0 ~ 50
℃
Storage Temperature -20 ~ 70
℃
Humidity 5 ~ 90% (non-condensing)
M odula t io n me t h o d
Operation mode
Receive Sensitivity
