Zoom B1 FOUR User Manual

Adjusting the pedal
Adjusting the pedal sensitivity
1.
While pressing , turn the power on.
This opens the PEDAL CALIBRATION screen.
2.
Operate the pedal as shown on the display, and press or each time.
Calibration is nished when “Complete!” appears.
NOTE
• Adjust the pedal sensitivity in the following cases.
– Stepping on the pedal has little effect.
– The volume and tone changes greatly even when the pedal is only pressed lightly.
• If “Error!” appears, start calibration again from the beginning.
54

Zoom B1 FOUR Specifications

General

Simultaneous Effects	5
Sampling Frequency	44.1 kHz
Tuner	Yes
A/D Conversion	24-bit
D/A Conversion	24-bit
Frequency Response	20 Hz - 20 kHz
Display	LCD
Input	1/4" phone jack
Output	1/4" phone jack
Expression Pedal	Yes
Inputs	1 x 1/4" (Instrument)
Outputs	1 x 1/4" (Headphones), 1 x 1/4" (Line Out)
Patches	50
