Zoom B1 FOUR User Manual

Adjusting the torque
1.
Insert a 5 mm hex wrench into the torque adjustment screw on the side of the pedal.
2.
Turn it clockwise to tighten the pedal and counterclockwise to loosen it.
Loosen Tighten
NOTE
Be careful because loosening the torque adjustment screw too much could cause it to become discon-
nected internally, making it impossible to keep the pedal in a xed position.
55

Zoom B1 FOUR Specifications

General

Simultaneous Effects	5
Sampling Frequency	44.1 kHz
Tuner	Yes
A/D Conversion	24-bit
D/A Conversion	24-bit
Frequency Response	20 Hz - 20 kHz
Display	LCD
Input	1/4" phone jack
Output	1/4" phone jack
Expression Pedal	Yes
Inputs	1 x 1/4" (Instrument)
Outputs	1 x 1/4" (Headphones), 1 x 1/4" (Line Out)
Patches	50
