Zoom Studio 1204 - Connections

Connections
Connect an electronic instrument, microphone, mixer, or other audio equipment to the 1204 as described below.
Before making any connections, set the power switches of all equipment to OFF.
If the equipment is on, sudden noise surges can lead to hearing damage or damage
to the equipment.
■ 9 ■
Precaution
DC9V 300mA
MIDI IN
MODEL 1204
ZOOM STUDIO
OUTPUT
RL
INPUT
R L/MONO
ZOOM CORPORATION
MADE IN JAPAN / FABRIQUÉ AU JAPAN
SERIAL NO.
POWER
MIC IN
INPUT OUTPUT
PEAK
MIDI CONTROL
WITH VOCODER, ROTARY
612 PROGRAMS
Microphone AC adapter
Electronic instrument Amplifier Keyboard
