zortrax M200 Fuse Replacement

The fuse protects your printer from short circuits and power overload. It is placed
between the power outlet and the switch on the left side of the printer. If your
machine does not start after pressing the power switch, at first you should check
if the power cable is connected to a power source. Then, you should check if the
LED on the power supply unit is on. If the diode is lit, the fuse is probably blown
and needs to be replaced. Follow the instructions provided in this manual to see
the correct replacement procedure.
The following manual shows the M200 repair work. For the M300, M200 Plus and M300
Plus, these procedures are the same.
page 3 / 8

zortrax M200 Specifications

General

Build Volume	200 x 200 x 180 mm
Layer Resolution	90-400 microns
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	SD card
Software	Z-Suite
Operating System	Windows, macOS
Frame	Aluminum
Printing Speed	up to 100 mm/s
Heated Bed	Yes
Bed Temperature	up to 110°C
Nozzle Temperature	up to 380°C
Power Consumption	300 W
Technology	FDM
Supported Materials	Z-ABS, Z-ULTRAT, Z-HIPS, Z-GLASS, Z-PETG, Z-ESD
Power Supply	100-240 V, 50/60 Hz
Dimensions	345 x 360 x 430 mm
Weight	13 kg
