10
ZOTAC ZBOX Giga
8. Connecting USB 3.0 device
Connect USB 3.0 devices such as external hard drives, SSDs and ash drives to
the USB 3.0 port.
9. Connecting an external USB IR receiver
The USB 2.0 ports also support external USB IR receiver.
10. Connecting an eSATA device
Connect one end of an eSATA device to the eSATA port.
11. Connecting to an HDMI display
Connect one end of an HDMI cable to the HDMI port on the system rear panel
and the other end to a HDMI-compatible display such as an HDTV or monitor.
(When both the HDMI and the DP are connected, the audio output is from HDMI
by default.)
12. Connecting an optical S/PDIF output
Connect a digital audio device via optical S/PDIF output.
13. Connecting audio ports
Connect audio devices (such as microphone, back surround and side surround) to
the audio ports.
Note: When your ZOTAC ZBOX Giga is not in use, unplug the power adapter or switch off the AC outlet to
conserve power.
8
9
10
11
12
13
9
