Operating elements
Aligning by way of control unit
Aligning the pantograph by way of the control unit is possible only in
the Machine module.
By way of the control unit the pantograph position can also be controlled with
reference to the screen display. This allows paths to be traveled quickly or slowly
or in 1 mm or 1/10 mm steps(increments).
Press the [U5] button below the screen display to activate manual pantograph
positioning.
Ö The following symbols are displayed at the bottom of the screen.
The control unit operator’s guide contains more detailed information
on using the menu keys.
Press button [U1] and hold down arrow button to move pantograph continuously
and fast.
Press button [U2] and hold down arrow button to move pantograph continuously
and slowly.
Press button [U3] and briey press arrow button to move pantograph in 1 mm
steps with each press.
Press button [U4] and briey press arrow button to move pantograph in 1/10 mm
steps with each press.
The pantograph responds straight away.
- Caution! - The pantograph travels at a very high speed.
Do not rest on the work table or lean against the table recesses
within the working range of the pantograph (Abb. 46) A collision
with the high-speed pantograph can cause bruising and injuries
resulting from crushing or shear forces. (Abb. 47).
Once you have aligned the pantograph, switch o the manual
pantograph positioning function. With manual pantograph position-
ing selected, the machine cannot be started.
