ZUMEX MINEX Operator's Manual

29
EN
PREPARATION
To start operating the juice extractor, proceed as follows:
Remove the appliance from its packaging and place it on a surface that is as horizontal as
possible.
Check that the electricity voltage is within the limits indicated on the machine characte-
ristics label which can be found on the cover of this manual and on the machine itself.
Place the feeder ramp on the machine as shown in Fig. 1
Plug the cable supplied with the machine into a standard socket with a ground connec-
tion, Fig. 2
Before using the machine, install the tap tting as shown in gures 3 and 4. Remove the
jug, open the top cover and remove the juice container. The tap tting and push button
are inside the jug. Take out both parts and install the tap. Keep the button for future use.
Replace the container, close the cover and replace the jug in the machine, in that order.
Check that the cover, juice container and peel container are properly inserted in place, as
otherwise the machine safety sensors will not allow it to be started.
OPERATION
Once the appliance is plugged into the mains at the correct voltage, activate the switch at
the rear of the machine (Fig. 2), and it will be ready to operate.
The machine operates as follows: the oranges on the ramp are automatically introduced
into the extractor system, where they are cut in half and then the juice is extracted by the
drums. Then the juice is deposited in the container or juice jug and the peel in the peel
container.
1
2
3
4
Remember: Use fruit with a diameter of no more than 80 mm
(Preferably between 65 and 78 mm).
5
6

ZUMEX MINEX Specifications

General

Product color	Orange

Weight and Dimensions

Width	365 mm
Height	720 mm
Weight	19000 g
