ZUMEX Speed S +plus User Manual

43
EN
Technical features
OTHER CHARACTERISTICS (For all models)
Voltage 100 V | 50-60 Hz 120 V | 60 Hz 220-240 V | 50-60Hz
Power 350 W (560 W Cooler) 320 W (560 W Cooler) 460 W (560 W Cooler)
Consumption 3.5 A (4.87 A Cooler) 2.7 A (4.87 A Cooler) 2 A (2.4 A Cooler)
Oranges per minute 36/43 40 37/40
Fruits* Oranges, tangerines, limes, grapefruits
Size of fruit 65-81 mm (45-67 mm with Kit S)
Feeder capacity 20 kg / 44 lb
Protection IPX4
Sound pressure level Lower 70 dB(A)
* For other fruits squeezed always check with your nearest dealer.
Model Weight Dimensions | Width x Height x Depht |
Speed Pro Basic
66.3 Kg 146.1 lb 593 x 584 x 980 mm 23.3” x 23” x 38.6”
Speed Pro Cooler Podium
116.1 Kg 259.6 lb 675 x 727 x 1837 mm 26.6” x 28.7” x 72.3”
Speed Up
76.7 Kg 169.2 lb 593 x 624 x 1050 mm 23.3” x 24.6” x 41.3”
Speed Up All-in-One Wide Black
133 Kg 293.3 lb 810 x 682 x 1775 mm 31.9” x 26.8” x 69.9”
Speed Up All-in-One Narrow Black
129.1 Kg 284.7 lb 710 x 682 x 1775 mm 28” x 26.8” x 69.9”
Speed Up All-in-One Wide Mirror
122.1 Kg 269.3 lb 805 x709 x 1774 mm 31.7” x 27.9” x 69.8”
Speed Up All-in-One Narrow Mirror
113.3 Kg 249.8 lb 700 x709 x 1774 mm 27.5” x 27.9” x 69.8”
Speed S +plus
83.5 Kg 184.1 lb 593 x 665 x 1050 mm 23.3” x 26.2” x 41.3”
Speed S +plus All-in-One Wide Black
131.5 Kg 290 lb 810 x 682 x 1775 mm 31.9” x 26.8” x 69.9”
Speed S +plus All-in-One Narrow Black
127.6 Kg 281.4 lb 710 x 682 x 1775 mm 28” x 26.8” x 69.9”
Speed S +plus All-in-One Wide Mirror
120.6 Kg 266 lb 805 x709 x 1774 mm 31.7” x 27.9” x 69.8”
Speed S +plus All-in-One Narrow Mirror
111.8 Kg 246.5 lb 700 x709 x 1774 mm 27.5” x 27.9” x 69.8”
Speed S +plus Tank All-in-One
110.1 Kg 242.8 lb 675 x699 x 1755 mm 26.6” x 26.3” x 69.1”
Instructions for use
Preparation
To start to extract juice, you must follow the steps below:
Unpack your juicer and place it on as flat a surface as possible.
Make sure that the mains voltage coincides with the voltage indicated on the machine
identification label that you will find on the machine.
Ensure that no obstacles hinder you during the unpacking process.
Before first use, we recommend that you clean the juicing system.
Please see the section entitled ‘Cleaning’.
Unpacking and start-up
Follow the instructions given, depending on the machine model you have purchased. The
following components could be loose and if so must be installed properly:
Speed Pro Basic
Right cover side outlet (2), Left cover side outlet (3), Power cable (15), Protector cable (16),
Plastic juice container (30), Inner plastic filter (31), Plastic juice filter (32), Peel bucket (33),
Drip try (34).
See Figures 1 and 2.
Speed Pro Cooler Podium
Right cover side outlet (2), Left cover side outlet (3), Power cable (15), Protector cable (16),
Plastic juice container (30), Inner plastic filter (31), Plastic juice filter (32), Cooler Unit (70),
Tank/Cooler Buoy (52).
See Figures 1 and 6. See section Podium Cooler (100) for information about your machine
stand.
