The letter A
appears blinking on
the display
Check to see if frozen oranges are being squeezed.
Check if peelings have piled up on the tray that holds squeezers.
Check to see if balls have been left un-tightened.
Check to see if peelings are left stuck to the inside of cups.
To unblock the machine, use an Allen key of 5mm which you will find at
the right side of the grid. Introduce it in the right side lateral hole
(Fig.21) and, with the machine switched off, turn the key clockwise till
cups are up and the machine is unblocked.
LOOK OUT: before switching the machine, make sure that the key is
out of the anchorage.
The cups break Nuts on the cups are improperly tightened.
Excess of washers under the balls.
The balls on the tray that holds squeezers are loose.
The blade is not properly positioned.
Do not place Dark-coloured cups with large Bright-coloured balls (Ø80).
Oranges are either too small or too large for the cups.
Blade breakage The blade has been placed over its shaft.
The balls break The Balls are loose.
The nuts on the cups are improperly tightened.
More than two washers have been placed under each ball.
Oranges are not
thoroughly
squeezed
Washers are missing under balls.
Orange peels are too thin; place a maximum of one washer under
balls.
Oranges dash out
from the paddle
The paddle shaft is too dry; proceed to grease it. (Fig. 18)
The machine does
not stop with cups
in vertical position.
The process that must follow to modify the STOP point
from the electronic plate is the following one:
- To disconnect the machine by means of the back switch.
- To connect again simultaneously that STOP is pressed. four numbers
will appear in the screen.
With the four numbers in screen (it appears 3 seconds) press
button ON. A number from the 0 to the 9 will appear on the left of the
screen. The shown number corresponds to tenth of second of delay in
not operating of the machine, for which and if you need to stop the
machine you have to select an inferior number than the shown one in
screen. In order to change this number, press ON (when the screen
shows the number to the left) number will change. Enabling electronic
to memorize this number, you will have to wait 5 seconds (the screen
will show then a number in the central position, corresponding to the
number of oranges selected).
Verify that the unemployment point is the correct one. If it’s not, repeat
the process with another value.
For any queries or request for spare parts, please state the model and identification
number of your machine (Fig.5).
7.4. LIST OF COMPONENTS
Code Description
0316000 BOTTLE RACK BODY
0316002 BOTTLE RACK TRAY
0316004 BOTTLE RACK
0502A00B COMPACT FRONT COVER
0503010 BASKET AND FEEDER RAMP
Code Description
0505002G SQUEEZING TRAY (GREY)
0505002R SQUEEZING TRAY (RED)
0505003G BLADE Z05 (GREY)
0505004G BALL 80 (BRIGHT GREY)
0505005G BALL 67 (DARK GREY)
