Zummo Z14 - Page 33

Not
enough juice is
being extracted from the
fruit
(Z14 Model)
The low-pass filter is missing.
(Z14 Self-service model) The ball washers (which are placed underneath
the balls) are missing.
Fruit peel is too thin. Place one extra washer under each ball.
Hooper is not delivering
fruits so the squeezing
area
Fruit is too big for the Fruit Classifiler in use.
Hooper is delivering
several oranges at the
same time into the
squeezing area
Fruit is too small for the Fruit Classifier in use.
Hopper not properly assembled. See section nº 12 of this manual.
For any advice or to request spare parts, you should state the model and serial number of
your machine (Fig. 2).
7.5. LIST OF COMPONENTS
0316000 BOTTLE RACK BODY
0316002 BOTTLE RACK TRAY
0316004 BOTTLE RACK
0505010A FASTENING NUT WITH RAKED JOINT
0505016-1 PEEL EXTRACTING BANDS
0508013 RUBBER SUPPORT 85MM
210810 DRIP TRAY DRAIN
210814 M20 NUT
210912 BOTTLE RACK SUPPORT
210916 GN TRAY GRID
210917 MECHANISED GN TRAY
211002 LEFT DOOR
211003 MDP RIGHT DOOR
211004 MSP RIGHT DOOR
211007 DRIP TRAY
211008 DRIP GRILL
211009 DRIP TRAY SUPPORT
1003033 PEELS BASKET 55L
1402003 Z14 CASING
1402017 DRIP TRAY
1402018 DRIP VENT
1402020 MECHANISED DRIP TRAY
1402021 COMPLETE DRIP TRAY
1403001 HOPPER TRACK
1403005 SEPARATOR 50-75
1403006 SEPARATOR 70-90
1403012 HOPPER BASKET
1403016-1 EXTERNAL BASKET 20KG
1403016-2 Z14 HOPPER BASKET 20KG
1403016-3 HOPPER TRACK 20KG
1403017 COMPLETE EXTERNAL BASKET 20KG
1405001 Z14 3MM FILTER
1405002 Z14 4MM FILTER
1405003 Z14 FILTER TRAY
1405005 Z14 JUICE TRAY
1405006 Z14 LARGE CUP
1405008 Z14 MEDIUM CUP
1405010 Z14 SMALL CUP
1405011 Z14 SMALL BALL
1405012A2 Z14 BLADE
1405016A SMALL Z14 SQUEEZING KIT
1405021A Z14 BLADE
1405022 Z14 LARGE BALL
1405023 Z14 MEDIUM BALL
1406006A CPU SILKSCREEN
1408001 Z14 BIN
1408002 TRAY BASE
1408003 Z14 DRIP TRAY
1408004 DRIP VENT
1408006-1 Z14 CALIBRATOR
1408014 BIN Z14
1408015 RIGHT CABINET CHUTE
1408016 LEFT CABINET CHUTE
1408017A Z14 TANK LID
1408018 Z14 TANK LID
1408019 Z14 TANK FILTER
1408020A Z14 TANK SUPPORT
1408021A Z14 TANK SHAKER
1408023 TOMLINSON SILICONE JOINT FAUCET
1408033 COMPLETE Z14 JUICE TANK
1409001 FAUCET TRAY
1409002A FAUCET JOINT
1409003 MAGNET HOLDER
1409005A FAUCET ROD
1409007 MAGNET HOLDER GUIDE
1409010 COMPLETE Z14 FAUCET TRAY
1409011 SELF SERVICE FILTER Ø7
1409012 BOTTOM FILTER Ø5
1410001 Z14 MD LID
1410002 Z14 MS LID
1410003 Z14 MDC LID
1411001 Z14 MDP LID
1411002 Z14 MSP LID
1411003 Z14 MDPC LID
1412002 DOOR MD/MS LHS
1412003 MD DOOR RHS
1412004 MS DOOR RHS
1503002 RING MAGNETIC UNIT
1605005 DIRTY WATER TUBE
1702004 HOOP BAG
2/13/9 TANK FAUCET
2/13/9-2 TOMLINSON TAP NUT
I-7985-M4X10 DIN-7985 STAINLESS STEEL BOLT M4X10
I-9021-M6 S. STEEL WASHER DIN-9021 M6
