2.3. Straightaway, disconnect both connectors of the capacitor and proceed for its discharge for
security (please touch both connectors at the same time with an insulated screwdriver).
Next step is to remove the locking arm; first we unscrew two hexagon socket screws on both
sides and then by stretching both sides of the locking arm out. Upon removal of the locking
arm we could be able to pull the mobile guideway out by unscrewing the bolt and the rubber
washer that fix it to the motor.
