Then
measure
from
the
same
point
to
the
stop
collar
of
selector
shaft
(fig.
51).
The
distance
must
not
be
larger
than
the
value
obtained
to
fig.
50.
Cor-
rect
any
backlash
in
gears
by
fitting
packing
washers
between
Ist
and
2nd
speed
gear;
play
must
be
eli-
minated
to
0
(fig.
52).
Note: The balls for the selector
gears should be coated with oil, not
with
grease,
to
stick
them
into
posi-
tion.
Before
fitting
selector
shaft,
check that stop pins of selector
shaft are correctly mounted, com-
plete with their annular springs.
Measuring Starter Spindle
Check distance of opposing teeth
between driver and kickstarter gear
on kickstarter spindle. This should
not exceed 0.8 mm. If it does, fit
packing washers between shap ring
and driver. A washer of I mm is
fitted to the short shaft stub as
standard (fig. 53).
With gauging bar and depth gauge,
measure distance between contact
face of right casing and stop collar
for stdrter spindle (fig. 54). Note
down the reading.
