Chapter 10 Home Networking
VMG/EMG/AM/DM/GM Series User’s Guide
257
Figure 130 Network Setting > Home Networking > TFTP Server Name
The following table describes the labels in this screen.
10.9 Technical Reference
This section provides some technical background information about the topics covered in this chapter.
LANs, WANs and the Zyxel Device
The actual physical connection determines whether the Zyxel Device ports are LAN or WAN ports. There
are two separate IP networks, one inside the LAN network and the other outside the WAN network as
shown next.
Figure 131 LAN and WAN IP Addresses
Table 66 Network Setting > Home Networking > TFTP Server Name
LABEL DESCRIPTION
TFTP Server
Name
Enter the IP address or the host name of a single TFTP server.
Cancel
Click Cancel to restore your previously saved settings.
Apply Click Apply to save your changes.
