2easy VULCAN DT821 - 9. S4 Module; S4 Module Call Codes and DIP Settings

2 EASY
-20-
IN
OUT
S4 MODULE
Call button
Name plate
Call codes
The DT821 automatically assigns the call codes to the connected module’s
buttons. Regardless of the structure of the call button module, the button
numbers are starting from the bottom
9. S4 Module
Connect to main
or last module
S4 Module
address settings
Connect to next
module
04
03
02
01
16
15
14
13
Call Code Call Code Call CodeDIP DIP DIP
08
07
06
05
20
19
18
17
12
11
10
09
24
23
22
21
1 2 3 4 5 6
ON
1 2 3 4 5 6
ON
1234
12341234 1234
5
55 56 6
ON
ONON ON
